14
ATTACHING WEIGHTS TO THE LEG LEVER
To use t h e Leg L e v e r (6), s l i de the d e s ired we i g h t
plates (not included) onto the weight tube on the Leg
Lever. Secure the weight plates with a Small Spring
Collar (37).
To use O l ympic w e i g ht plat e s , slide a n Olympic
Adapter (23) onto the weight tube, and tighten the
Set Screw (57) in the Olympic Adapter. Secure
the Olympic weight plates with a Large Spring
Collar (38).
6
5
38
37
57
23
4
WARNING: When using
the Leg Lever (6), always secure weight
plates with a Spring Collar (37, 38).
Do
not place more than 150 lbs. (68 kg) on the
Leg Lever.
ATTACHING THE CURL PAD
To use t h e Curl P a d (17), r e m ove the Adjus t m e nt
Knob (22), insert the Curl Post (7) into the Post
Frame (4), and then tighten the Adjustment Knob
into the Post Frame and into one of the adjust-
ment holes in the Curl Post. Make sure that the
Adjustment Knob is in one of the adjustment
holes.
7
22
17
4
