10
11
12
11. Insert the Curl Post (6) into the Front Leg (4).
Insert the Curl Post Knob (24) into the Front
L
eg (4) and into one of the adjustment holes in
the Curl Post (6), and tighten the Curl Post
K
nob. Make sure that the Curl Post Knob is
inserted through one of the adjustment
holes.
6
4
2
4
9
9
34
34
34
35
35
7
12. Insert a Base Stabilizer (9) into the Base (7).
Attach the Base Stabilizer with five M10 x 20mm
Screws (34) and five M10 Washers (35).
Attach the other Base Stabilizer (9) to the
Base (7) in the same way.
