Weidmüller ACT20X - Page 107

1066540000/00/02.09 107
54
53
52
51
44
43
42
41
24
23
22
21
14
13
12
11
ACT20X
ACT20X
CBX200 with Configuration Software
Hazardous area
Class I/II/III, Division 1, Group A,
B, C, D, E, F, G
or Class I Zone 0/1/2, Group IIC,
IIB, IIA
or Class I Zone 20/21
Non Hazardous area or
Class I, Dicision 2, Group
A, B, C, D T4
or Class I, Zone 2, Group
IIC, IIB, IIA T4
Configuration in safe area only!
-
+
54
53
52
51
44
43
42
41
24
23
22
21
14
13
12
11
CBX200 with Configuration Software Configuration in safe area only!
0/4-20 mA
Current source
Illustration 7-35: FM Installation Drawing
Supply / Input
(terminal 41, 42, 43, 44)
(terminal 51, 52, 53, 54)
U
m
: 253 V, max. 400 Hz
