1066540000/00/02.09
9
4. Introduction
4.1 Product Description
4.1.1 Family ACT20X
Order No. Type Description Function
8965340000 ACT20X-HDI-SDO-RNO-S NAMUR isolator - relay NO NAMUR in (from Ex)
to relay out
8965350000 ACT20X-HDI-SDO-RNC-S NAMUR isolator - relay NC NAMUR in (from Ex)
to relay out
8965360000 ACT20X-HDI-SDO-S NAMUR isolator NAMUR in (from Ex)
to digital out
8965370000 ACT20X-2HDI-2SDO-RNO-S 2 Ch. NAMUR isolator -
relay NO
2x NAMUR in (from Ex)
to 2x relays out
8965380000 ACT20X-2HDI-2SDO-RNC-S 2 Ch. NAMUR isolator -
relay NC
2x NAMUR in (from Ex)
to 2x relays out
8965390000 ACT20X-2HDI-2SDO-S 2 Ch. NAMUR isolator 2x NAMUR in (from Ex)
to 2x digital out
8965400000 ACT20X-SDI-HDO-L-S Solenoid / alarm driver,
L = low current max. 35 mA
digital in to safe digital out
(to Ex IIC)
8965410000 ACT20X-SDI-HDO-H-S Solenoid / alarm driver,
H = high current max. 60 mA
digital in to safe digital out
(to Ex IIB)
8965420000 ACT20X-2SDI-2HDO-S 2 Ch. Solenoid / alarm driver,
low current max. 35 mA
2x digital in to 2x safe digital out
(to Ex)
8965430000 ACT20X-HAI-SAO-S HART-transparent
repeater
mA in (from Ex) to mA out
with HART transparency
8965440000 ACT20X-2HAI-2SAO-S 2 Ch. HART-transparent
repeater
2x mA in (from Ex) to 2x mA out
with HART transparency
8965450000 ACT20X-SAI-HAO-S HART-transparent driver mA in to mA out (to Ex)
with HART transparency
8965460000 ACT20X-2SAI-2HAO-S 2 Ch. HART-transparent
driver
2x mA in to 2x mA out (to Ex)
with HART transparency
8965470000 ACT20X-HTI-SAO-S Temperature / mA converter temperature in (from Ex)
to mA out
8965480000 ACT20X-2HTI-2SAO-S 2 Ch. temperature / mA
Converter
2x temperature in (from Ex)
to 2x mA out
8965490000 ACT20X-HUI-SAO-S Universal converter universal analog in (from Ex)
to analog (V / mA) + trip relay
out
Table 4-1: Family ACT20X
