54 1066540000/00/02.09
Appendix
Appendix A. Installation drawings ACT20X-HDI-SDO
IECEx Installation drawing
ACT
20X-HDI-SDO NAMUR Pulse Isolator
The module is available in the following variants:
Order No. Installation Drawing No. IECEX Type
8965340000 4 50102 Bl. 3-4 ACT20X-HDI-SDO-RNO-S
8965350000 4 50102 Bl. 3-4 ACT20X-HDI-SDO-RNC-S
8965360000 4 50588 Bl. 3-4 ACT20X-HDI-SDO-S
8965370000 4 50589 Bl. 3-4 ACT20X-2HDI-2SDO-RNO-S
8965380000 4 50589 Bl. 3-4 ACT20X-2HDI-2SDO-RNC-S
8965390000 4 50590 Bl. 3-4 ACT20X-2HDI-2SDO-S
DANGER
For safe installation of ACT20X-HDI-SDO the following must be observed: The module may
only be installed by qualified personnel familiar with the national and international laws,
directives and standards that apply to this region.
The year of manufacture can be taken from the first two digits in the serial number.
CBX200 – WI-Manager Software
For in
stallation in Zone 2 / Division 2 the following must be observed:
- The CBX200 is an interface cable for software.
- Configuration must be performed only in a safe area.
IECEx Certificate IECEx KEM 09.0072 X
Marking Ex nA nC IIC T4 Gc
[Ex ia Ga] IIC / IIB / IIA
[Ex ia Da] IIIC
Standards IEC60079-15: 2005, IEC60079-11: 2006, IEC60079-0: 2007
IEC60079-26: 2006, IEC61241-0: 2004, IEC61241-11: 2005
