7.3 ACT20X-SDI-HDO (Solenoid/Alarm Driver)
7.3.1 Description
The ACT20X-SDI-HDO is a solenoid/alarm driver for the control of solenoids, acoustic alarms and LEDs
mounted in the hazardous area (Ex Zone 0).
The following solenoid/alarm drivers are available:
Order No. Type Description
8965400000 ACT20X-SDI-HDO-L-S solenoid/alarm driver, L = low current max. 35 mA
8965410000 ACT20X-SDI-HDO-H-S solenoid/alarm driver, H = high current max. 60 mA
8965420000 ACT20X-2SDI-2HDO-S 2-channel solenoid/alarm driver, low current max. 35 mA
7.3.2 Status/Alarm LEDs
51
CH2
41
54
44
21 22
23
24
ACT20X
PWR
11 12
13
14
CH1
LED 1
LED 2
LED 3
Illustration 7-7: Status/Alarm LEDs
