34 1066540000/00/02.09
Condition Green LED Ch. 1:
Red LED
Ch. 2:
Red LED
Status Relay,
N.C.
Device OK Flashing OFF OFF Energized
No supply OFF OFF OFF De-energized
Device defective OFF ON ON De-energized
Ch. 1 defective (ch. 2 OK) Flashing ON OFF De-energized
Ch. 2 defective (ch. 1 OK) Flashing OFF ON De-energized
Channel 1, signal OK Flashing OFF OFF Energized
Ch. 1, wire short / break Flashing Flashing OFF De-energized
Channel 2, signal OK Flashing OFF OFF Energized
Ch. 2, wire short / break Flashing OFF Flashing De-energized
