Weidmüller ACT20X - Page 16

16 1066540000/00/02.09
2 Connect the CBX200 USB jack, as shown in the
illustration:
1 23
Illustration 5-9: CBX200 USB Connection
1 Jack connection under front flap
2 CBX200 with USB connection
3 PC
3 See WI-Manager documentation for further
information.
