ACT20X
CBX200 with Configuration Software Configuration in safe area only!
Hazardous area
Class I/II/III, Division 1, Group A,B,C,D,E,F,G
or Class I, Zone 0/1 Group IIC
Non Hazardous area or
Class I, Division 2, Group A,B,C, D T4
or Class I, Zone 2 Group IIC T4
Illustration 7-17: FM Installation Drawing
Ex Input Supply / Output
CH1 (14, 12) CH2 (24, 22) (terminal 51…54)
(terminal 41…44)
U
o
/Vt:10.6 V DC U
m
: 253 V, max. 400 Hz
I
o
/I
sc
: 12 mA (terminal 51,52)
P
o
/P
t
: 32 mW Supply voltage: 19.2…31.2 V DC
L
o
/R
o
L
a
/R
a
: 1150 μH/Ω Max. power consumption: 3 W
Group IIC IIB IIA
Group A,B C,E,F D,G
C
o
/C
a
2.0 μF 6.0μF 18μF
L
o
./L
a
260 mH 780 mH 1000 mH
