896540 (ACT20X-SDI-HDO-L-S),
896542 (ACT20X-2SDI-2HDO-S),
Terminal 11–13 / 21–23
Co Lo Lo/Ro
Uo 28 V IIC 80 nF 3.5 mH 50 µH/Ω
Io 100 mA IIB 640 nF 14.2 mH 201 µH/Ω
Po 0.70 W IIA 2.1 µF 27.6 mH 402 µH/Ω
896540 (ACT20X-SDI-HDO-L-S),
896542 (ACT20X-2SDI-2HDO-S),
Terminal 11–14 / 21–24
Co Lo Lo/Ro
Uo 28 V IIC 80 nF 2.9 mH 46 µH/Ω
Io 110 mA IIB 640 nF 12.8 mH 184 µH/Ω
Po 0.77 W IIA 2.1 µF 22.8 mH 369 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–12
Co Lo Lo/Ro
Uo 28 V IIC 80 nF 2.69 mH 44 µH/Ω
Io 115 mA IIB 640 nF 10.8 mH 176 µH/Ω
Po 0.81 W IIA 2.1 µF 20.8 mH 353 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–13
Co Lo Lo/Ro
Uo 28 V IIC – – –
Io 125 mA IIB 640 nF 9.1 mH 162 µH/Ω
Po 0.88 W IIA 2.1 µF 17.6 mH 325 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–14
Co Lo Lo/Ro
Uo 28 V IIC – – –
Io 135 mA IIB 640 nF 7.8 mH 150 µH/Ω
Po 0.95 W IIA 2.1 µF 15.1 mH 301 µH/Ω
Terminal (51, 52)
Supply:
Voltage 19.2…31.2 V DC
Power max. 3.5 W
