Weidmüller Crimpfix 2.5 M - 11 Trouble Shooting

Stripping and crimping machine Crimpfix 2.5 M
08-09-19-DK-Operating Manual_gb.doc / 2008-09-19 15
11. Trouble shooting
See chapter 3.8. Using risks
Trouble Elimination
Double crimp See Jammed wire
Jammed wire Remove the Magazine.
If there is a ferrule in the crimping tool, take it away.
Remove the feeding funnel.
If the feeding funnel is not removable:
3x
M.Motor
E
5s Confirm → manual operation
or Move carefully stepwise forwards or backwards
until the feeding funnel is removable.
C
Starting position
Take out stripping waste.
Insert the feeding funnel and fix it.
E
Exit and back to the operating menu
Insert in the magazine.
Not able to put in a cable Holding clamps are not in starting position
Remove the magazine
3x
M. Motor
E
5s Confirm → manual operation
C
Starting position
E
Exit and back to the operating menu
Insert in the magazine.
Machine is not starting Machine is not in operating mode
Remove the magazine
3x
M. Motor
E
5s Confirm → manual operation
Insert wire
Starting switch S1 is triggered (*) or damaged.
C
Starting position
E
Exit and back to the operating menu
Insert in the magazine.
Wire is not stripped correct Stripping depth is not adjusted correctly.
See chapter 9.2 Adjusting Stripping Depth
Single strands are cut Stripping depth is not adjusted correctly.
See chapter 9.2 Adjusting Stripping Depth
