CHUTES
The Chutes of the PrimoCombi are designed to be easily removed for cleaning. Each chute slips and
locks into place on a bar under each of the Weigh Buckets.
For ease of installation, the Chutes should be mounted before any of the Weigh Buckets. Doing so leaves
more room to slip the Chutes into place.
Install the chutes onto the bar that is fixed to the PrimoCombi frame. Each Chute is labelled with the
number of the lane that it belongs to. Each Chute has a mounting bracket located on its underside.
CHUTE SHOULD
SIT IN MOUNTING
BAR AS SHOWN
BRACKET
FOR
MOUNTING
ONTO BAR
