X25. ’hole 2
Y25. ’hole 3
G98 X5. ’hole 4, and setting to return to the initial point
G80
M05 ’spindle stop
M02
Special Canned Cycle
Description:
Unit of length: millimeter (mm)
Unit of angle: degree
1 meter=1000mm, one full circle= 360 degrees
Special canned cycle instructions (G34-37) must be used together with standard canned cycle
instructions (G73-89).
For Example:
G81 Z-20 R-5 F100 K0
G34 X10 Y10 I10 J90 K10
Standard canned cycle instructions must be written before special canned cycle instructions;
when the execution of a special canned cycle instruction is finished, the standard canned cycle
instruction remains effective until canceled.
For Example:
G81 Z-20 R-5 F100 K0 ’specifying the cycle action
G34 X10 Y10 I10 J90 K10 ’drilling10 holes around a circle
X100 ’drilling another hole, not influenced by the previous G34
If there is no standard canned cycle instruction when executing a special canned cycle instruction,
the system will report an error.
If the following instructions are executed:
G0 X0 Y0 Z0
G34 X10 Y10 I10 J90 K10
…
An error prompt as following will pop up:
G34/35/36/37 instruction error: special canned cycle instructions do not match, with no designation.
A correct form should be like:
G0 X0 Y0 Z0
G81 Z-20 R-5 F100 K0
G34 X10 Y10 I10 J90 K10
…
