WEIHONG ELECTRONIC Ncstudio User Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
68 Specialized, Concentrated, Focused
6 Customize and Extend Command M
The user can customize command M and G code by writing subprograms in public.dat.
Subprogram no. 200~999 is used by internal interpreter engine. The code range of command M
is 200~599, while that of G code is 600~999.
As a result, command M 0~99 plus 200 is regarded as the corresponding subprogram, while G
code 0~99 plus 600 is regarded as the corresponding subprogram.
Program Example for Custom and Extended M Command:
’Conditional statement ―if‖ can be used to set the actions (like gear shift) during spindle rotating
O202
M17
’spindle CW (only one direction supported)
O203
M901 H2 P1
G04 P5
M17
’spindle CCW (only one direction supported)
O204
M901 H2 P1
G04 P5
M17
’spindle stop
O205
M901 H2 P0
G04 P5
M17
’coolant on
O208
M901 H24 P1
G04 P5
M17
’coolant off
O209
M901 H24 P0
G04 P5
M17
