11. Technical data
MEDUMAT Standard a
Dimensions
LxBxH in mm
190x110x90
inc. connections
Weight incl.
accessories
approx. 1.1 kg
Prod. category
93/42/EEC
II b
Operating
parameters
Temperature range
Humidity
Air pressure
–18 °C to +60 °C
15 % to 95 %
70 kPa to 110 kPa
Storage/transport
Temperature range
Humidity
Air pressure
–40 °C to +70 °C
15 % to 95 %
70 kPa
(a)
to 110 kPa
Electromagnetic
compatibility (EMC)
following EN60601-1-2
and EN 794-3:
– Interference
suppression
– Interference immunity
EN 55011
EN 61000-4 Parts 2, 3 and
8
Control
Timing pulse, constant
pressure, constant volume
Gas input Medicinal oxygen
Operating pressure 2.7 to 6.0 bar
(b)
Minimal gas volume
required
70 l/min O
2
Insp-exp. ratio
assisted ventilation
1:1.67
1:1 to 1:2.33 variable
Ventilation frequency
infinitely variable
from 5 to 40 min
-1
Minute volume (MV)
infinitely variable
from 3 to 20 l/min
Tiidal volume
75 to 4,000 ml, infinitely
variable
MV tolerances:
room temp. (20 °C)
–18 °C to +60 °C
±20%
±20%
max. ventilation
pressure
infinitely variable
from 20 to 60 mbar
(c)
O
2
concentration
– Air Mix
– No Air Mix
see page 72
100% O
2
High-pressure gas
connection
External thread G 3/8
Connection to
ventilation tube
External diameter 13 mm
Power supply
life expectancy
max. storage
maintenance-free lithium
battery 3.6 V; 5.2 Ah,
> 2 years
10 years after delivery
Auxiliary energy for
alarm system
max. storage
Button cell CR2430
10 years after delivery
F1 fuse T500 L250V
(a.) Under normal atmospheric conditions, 70 kPa
correspond to a maximum altitude for use of
approx. 3,000 meters.
(b.) 1 bar =ˆ 100 kPa
(c.) 1 mbar =ˆ 1 hPa
