2 Product description
2.1 Schematic diagram of the weinor PergoTex II Basic/ LED
Figure 1: Schematic diagram of the weinor PergoTex II Basic/ LED
1
Transom 45x60 mm
4
Wall bracket
2
LED spotlight
5
Fabric
3
Transom 80x60 mm
6
Side channel
