2.2 Schematic diagram of the weinor PergoTex II / LED
Figure 2: Schematic diagram of the weinor PergoTex II Basic/ LED
1
Post
6
Transom 80x60 mm
2
Guttering
7
Wall bracket
3
Post plate
8
Safety shield with guttering safety shield
4
LED spotlight
9
Fabric
5
Transom 45x60 mm
10
Side channel
