Weishaupt WG20 1-C Z-LN Series User Manual

Installation and operating instruction
Gas burner WG20…/1-C Z-LN
4 Installation
83054602 1/2020-01 La
24-96
Rotate burner flange1 180° and mount with flange gasket.
Rotate burner 180° and fit screws 2 to burner flange.
The aperture between combustion head and refractory should be filled with
flame-proof, resilient insulating material (do not make solid).
180°
2
1
Check setting of electrodes [ch.9.5].
Fit mixing head [ch.9.3].
