Installation and operating instruction
Gas burner WG20…/1-C Z-LN
9 Servicing
83054602 1/2020-01 La
64-96
9.13 Replacing coil on multifunction assembly
Observe notes on servicing [ch.9.1].
Ensure correct voltage and solenoid number when replacing the solenoid coil.
Undo screw 1.
Remove cap2.
Replace solenoid coil3.
3
2
1
