Installation and operating instruction
Gas burner WG20…/1-C Z-LN
13 Spares
83054602 1/2020-01 La
87-96
Pos. Description Order No.
3.01 Mixing head WG20N/1-C cpl. (Natural Gas)
– Standard 232 210 14 052
– extended by 100 mm* 230 210 14 072
– extended by 200 mm* 230 210 14 082
– extended by 300 mm* 230 210 14 092
Mixing head WG20F/1-C cpl. (LPG)
– Standard 233 210 14 012
– extended by 100 mm* 230 210 14 132
– extended by 200 mm* 230 210 14 142
– extended by 300 mm* 230 210 14 152
3.02 Lock housing complete 232 210 14 022
3.03 Mixing tube WG20N/1-C cpl. (Natural Gas)
Ø internal 32 mm
– Standard 232 210 14 082
– extended by 100 mm* 230 210 14 042
– extended by 200 mm* 230 210 14 052
– extended by 300 mm* 230 210 14 062
Mixing tube WG20F/1-C cpl. (LPG)
Ø internal 18 mm
– Standard 233 210 14 022
– extended by 100 mm* 230 210 14 102
– extended by 200 mm* 230 210 14 112
– extended by 300 mm* 230 210 14 122
3.04 Nozzle element 232 200 14 467
3.05 Screw M4 x 16 Torx-Plus 20IP 409 224
3.06 Diffuser 36 x 95 232 200 14 417
3.07 Nozzle insert 232 200 14 397
3.08 Screw M4 x 8 Torx-Plus 20IP 409 235
3.09 Bracket for electrodes 232 200 14 437
3.10 Ignition electrode isolator 6 x 80 232 200 14 217
3.11 Sensor electrode 232 100 14 207
3.12 Ignition and sensor cable
– 380 mm (Standard) 232 110 11 032
– 480mm (for 100 mm extension)* 230 110 11 082
– 600mm (for 200 mm extension)* 232 310 11 042
– 700mm (for 300 mm extension)* 232 400 11 042
3.13 Carrier 232 200 14 037
3.14 Carrier 232 200 14 047
3.15 O ring 32 x 3 NBR70 ISO 3601 445 095
3.16 Adjusting screw 232 210 14 047
3.17 Hexagonal nut M8 left DIN 934 -8 411 413
3.18 Spring washer A5 DIN 137 431 613
3.19 Hexagonal nut M5 DIN 985 411 203
3.20 Screw G⅛A DIN 908 409 004
3.21 Sealing ring 10 x 13.5 x 1.5 DIN 7603 441 033
3.22 View port glass 241 400 01 377
* Only in conjunction with combustion head extension.
