Weishaupt WG20 1-C Z-LN Series User Manual

Installation and operating instruction
Gas burner WG20…/1-C Z-LN
13 Spares
83054602 1/2020-01 La
89-96
Pos. Description Order No.
4.01 Combustion manager W-FM10 230 V / 50/60 Hz 600 475
– Micro fuse T6.3H, IEC 127-2/5 483 011 22 457
4.02 Adapter ring 22 x 4 for extension 600 358
4.03 Reset button extension AGK20.19 600 357
4.04 Cover clip AGK63 600 312
4.05 Plug unit ST18/7 716 549
4.06 Plug unit ST18/4 716 546
4.07 Plug-in switch ST18/4 version Z 130 103 15 012
4.08 Ignition unit type W-ZG01603 229 230 V 100 VA 603 229
4.09 Closing plug for ignition unit 603 224
4.10 Screw M4 x 42 Combi-Torx-Plus 20IP 409 260
4.11 Plug cable No. 3 fan motor 241 050 12 062
4.12 Plug cable No. 5 W-MF 232 110 12 052
4.13 Plug cable No. 11 air pressure switch 232 110 12 022
4.14 Plug cable No.12 gas pressure switch 232 050 12 022
4.15 Ionisation cable No. 13 232 310 12 012
