Installation and operating instruction
Gas burner WG20…/1-C Z-LN
13 Spares
83054602 1/2020-01 La
91-96
Pos. Description Order No.
5.01 Double nipple R1 x 80 with Loctite 139 000 26 747
5.02 Elbow A1-1-Zn-A 453 123
5.03 Double nipple R1 x 50 with Loctite 139 000 26 737
5.04 Flange W-MF
– 507 Rp1 605 233
– 512 Rp1 605 228
5.05 Pressure test nipple G
1
/8 A 453 001
5.06 O ring
– 57 x 3 W-MF 507 445 519
– 75 x 3.5 W-MF 512 445 520
5.07 Multifunction assembly
with gas pressure switch
– W-MF SE 507 S22 230V 605 320
– W-MF SE 512 S22 230V 605 321
5.08 Solenoid coil
– W-MF 507 No. 032P 220-240V 605 255
– W-MF 512 No. 042P 220-240V 605 257
5.09 Breather plug with filter element G
1
/8 605 302
5.10 Pressure switch GW 50 A5/1 5 … 50 mbar
with screws and O ring
691 378
5.11 O ring 10.5 x 2.25 445 512
5.12 Filter insert with seal
– W-MF 507 605 253
– W-MF 512 605 254
5.13 Flange W-MF
– 507 Rp¾ 605 227
– 507 Rp1 605 233
– 512 Rp1 605 228
5.14 Double nipple
– R¾ x 50 with Loctite 139 000 26 727
– R1 x 50 with Loctite 139 000 26 737
5.15 Isolating valve with TAE
– 998 N G¾ CE-TAS for Gas PN1 454 596
– 998 N G1 CE-TAS for Gas PN 1 454 597
Isolating valve without TAE
– 984 D Rp¾ PN 40/MOP5 454 660
– 984 D Rp1 PN 40/MOP5 454 661
