Parameter setting for your heating system
9.1 Parameter setting following commissioning
Parameter group No. Parameter Setting range Factory Setting during
setting commissioning
Heat circuit 1 Heat circuit 2
Setting value 50 Normal temp Economy temp…35°C 21.5 _____________ _____________
51 Economy temp Frost…Normal temp 16 _____________ _____________
52 Frost protect 4…Economy temp 10 _____________ _____________
53 S/W switchover 8…30°C 20 _____________ _____________
54 Gradient --- 3…40 15/*_ _ _ _____________ _____________
55 DHW setpoint DHW set temperature 50 _____________
Type operation 70 Type operation Standby Program1 HC1: ________ HC2: ________
(for other Program3 HC3: ________
heat circuits HC) Program2 HC4: ________
Program1 HC5: ________
Normaltemp HC6: ________
Economy temp HC7: ________
Summer HC8: ________
HC9: ________
71 Error message ––
Parameter group No. Parameter Factory setting
Heat program 1 11 Heat cycle Mon Mon to Fri 06:00h to 22:00h Normal temperature
12 Heat cycle Tue
13 Heat cycle Wed
14 Heat cycle Thur
15 Heat cycle Fri
16 Heat cycle Sat Sat and Sun 07:00h to 23:00h Normal temperature
17 Heat cycle Sun
18 Heat cycle Week
Heat program 2 21 Heat cycle Mon Mon to Fri 05:30h to 08:30h Normal temperature
22 Heat cycle Tue 12:00h to 22:00h Normal temperature
23 Heat cycle Wed
etc.
Sat and Sun 07:00h to 23:00h Normal temperature
28 Heat cycle Week
Heat program 3 31 Heat cycle Mon Mon to Fri 07:00h to 22:00h Normal temperature
32 Heat cycle Tue
etc.
Sat and Sun 07:00h to 24:00h Normal temperature
38 Heat cycle Week
DHW 41 DHW cycle Mon Mon to Fri 06:00h to 22:00h Normal temperature
program 42 DHW cycle Tue
etc.
Sat and Sun 07:00h to 23:00h Normal temperature
48 DHW cycle Week
Program 5 1 Prog cycle Mon Mon to Fri 06:00h to 06:30h Contact closed
2 Prog cycle Tue Mon to Fri 11:00h to 11:30h
etc. 17:00h to 17:30h
Sat and Sun 07:00h to 07:30h
11:00h to 11:30h Contact closed
17:00h to 17:30h
8 Prog cycle Week
* WRS-CPU-B2/E
Please ask the heating engineer to complete this table.
Personal heating times can be entered by you on the
intended page.
