3. Technical data
3.1 General Specications
Operating voltage 24V DC +/- 10%
Power consumption typ. 40mA (without 24 V brake)
Power consumption brake 1.0 to 2.0 DC (depending on type)
Digital inputs Level: LOW: 0V to 5V
HIGH: 15V to 30V
Input current: 6mA
Digital outputs Output current: 100 mA (outputs: 4, 6, 7, 8, 9, 10)
Output current: 2.0 A (outputs: C, D, E)
EMV according to EC directive 89/336/EEC
Applicable harmonised standards:
EN 61 000-3 (harmonic current emissions)
EN 61 000-4 (disturbance immunity)
EN 55014-1 (interference emission)
Permitted temperature ranges Storage: -25 °C to 55 °C (-13 °F to 135 °F)
Operation: 0 °C to 40 °C (-32 °F to 104 °F)
Humidity 5 to 95%, without condensation
Dimensions Eurocard: 100 x 160mm
