4 Moving the appliance
Back to contents >
Merrychef conneX Installation and User Manual
28
_______________________________________________________________________________________________________________________________
4.2 Moving the appliance to the installation location
Space required for conveying the appliance
Make sure that there is enough width and height along the entire route used for conveying the appliance to ensure it can get
through to its installation location.
The table below shows the dimensions of the appliance including packaging, which are needed to determine the minimum
doorway dimensions required to allow the appliance to be brought to its installation location:
Minimum door opening
conneX 12
Width
[mm]
520
[in]
20.5
Height
[mm]
855
[in]
33.7
Depth
[mm]
820
[in]
32.3
conneX 16
Width
[mm]
620
[in]
24.4
Height
[mm]
855
[in]
33.7
Depth
[mm]
820
[in]
32.3
Load bearing capability for conveying the appliance
Provide moving equipment that is rated capable of carrying the load.
Empty weight of the appliance
ConneX 12 High Power version
[kg]
68.7
[lbs]
151
ConneX 12 Standard Power version
[kg]
60.0
[lbs]
133
ConneX 16 version
[kg]
79.2
[lbs]
175
Moving the appliance to the installation location
Please observe the following points when conveying the appliance:
▪ Always move the appliance on a pallet.
▪ Always move the appliance in an upright position.
▪ Move the appliance slowly and carefully and secure it against tipping over.
▪ Make sure that you do not knock against things with the appliance.
▪ Avoid moving the appliance along uneven routes or up or down slopes/steps.
▪ Do not lift the oven by the handle but always use the hand lifting points.
