5 Setting up the appliance
Merrychef conneX Installation and User Manual
_______________________________________________________________________________________________________________________________
5.5 Mounting the appliance on a work surface
Rules for setting up the appliance
Observe the following rules to ensure that the appliance is installed in a stable situation:
▪ It must be possible to set up the work surface in the installation position so that it cannot tip over or slide about.
The supporting surface must comply with the requirements.
▪ The work top must have a non-slip surface.
Merrychef conneX
®
base seal details:
According to Section 5.20.2 of NSF4;
Counter-mounted equipment shall be designed and manufactured to be:
▪ Portable; or
▪ Sealed to the counter; or
▪ Elevated on min. 4” legs that allow easy ingress for cleaning
The Merrychef conneX
®
oven is factory fitted with a self-sealing base-to-counter gasket that meets the requirements for
NSF4 counter-mounted equipment.
Prepare a flat and thoroughly CLEAN, dry surface for the oven.
Unpack the oven following the instructions in section 5.3 and lift the oven onto the
prepared surface. (Ensure 2 people to lift).
WARNING
▪ Don't lift the oven from the handle.
▪ Risk of crushing from the appliance tipping over.
The base of the conneX is sealed to the counter with a rubber gasket affixed to the
base of the oven in compliance with sealed counter mounted equipment directive of
NSF4. The gasket is self-sealing to the installation surface, no further adhesive is
necessary.
