4.2 Moving the appliance to the installation location
Space required for conveying the appliance
Make sure that there is enough width and height along the entire route used for conveying the appliance to ensure it can get
through to its installation location.
The table below shows the dimensions of the appliance including packaging, which are needed to determine the minimum
doorway dimensions required to allow the appliance to be brought to its installation location:
Minimum door opening
Width
[mm]
535
[in]
21.1
Height
[mm]
850
[in]
33.5
Depth
[mm]
895
[in]
35.3
Load bearing capability for conveying the appliance
Provide moving equipment that is rated capable of carrying the load.
Empty weight of appliance
e2s High Power version
[kg]
61.0
[lbs]
134
e2s Standard Power version
[kg]
51.7
[lbs]
114
Moving the appliance to the installation location
Please observe the following points when conveying the appliance:
▪ Always move the appliance on a pallet.
▪ Always move the appliance in an upright position.
▪ Move the appliance slowly and carefully, and secure it against tipping over.
▪ Make sure that you do not knock against things with the appliance.
▪ Avoid moving the appliance along uneven routes or up or down slopes/steps.
▪ Do not lift the oven by the handle but always use the hand lifting points.
