Directions for use Digital MacroView 13
Using the throat illuminator
The Welch Allyn Digital MacroView can transform into a throat
illuminator. While using the throat illuminator there are no images
available on screen or for capture.
1. Grasp the otoscope section with the left hand.
2. Grasp the throat illuminator’s collar at (under the silver ring).
3. Hold the throat illuminator collar stationary, twist the
otoscope section counterclockwise until the otoscope head
is removed.
To replace otoscope section, align the otoscope section with
the top of the throat illuminator and turn clockwise.
WARNING It is important to note that while the throat
illuminator section provides an excellent source of
general illumination, avoid more than momentary direct
skin contact due to possible heat build up.
Throat
Illuminator
Throat
Illuminator
