WeldKing COOLTIG220 - Page 47

Manual no. WDT90100 Page 44
CoolTig - 220
Standard collet body
B
Collet body 1/8”, Φ 3.2mm bore 10N29
Collet body 0.020”,Φ 0.5mm bore 10N30
Collet body 0.040”,Φ 1.0mm bore 10N31
Collet body 1/16”, Φ 1.6mm bore 10N32
Collet body 3/32”, Φ 2.4mm bore 10N28
Standard collet body 5/32’’,Φ 4mm bore 406488
Standard ceramic cup
C
Standard ceramic cup 1/4”, Φ 6mm bore 10N50
Standard ceramic cup 5/16”, Φ 8mm bore 10N49
Standard ceramic cup 3/8”, Φ 10mm bore 10N48
Standard ceramic cup 1/2”, Φ 13mm bore 10N47
Standard ceramic cup 5/8”, Φ 16mm bore 10N46
Standard ceramic cup 3/4”, Φ 19mm bore 10N45
Standard ceramic cup 1/4”, Φ 6mm bore 10N44
Standard long ceramic cup
D
Long ceramic cup 5/16”, Φ 8mm bore 10N49L
Long ceramic cup 3/8”, Φ 10mm bore 10N48L
Long ceramic cup 7/16”, Φ 11mm bore 10N47L
