Manual no. WDT90100 Page 45
CoolTig - 220
Stubby series collet
E
Stubby Collet 0.020”, Φ 0.5mm bore 10N21S
Stubby Collet 0.040”, Φ 1.0mm bore 10N22S
Stubby Collet 1/16”, Φ 1.6mm bore 10N23S
Stubby Collet 3/32”, Φ 2.4mm bore 10N24S
Stubby Collet 1/8”, Φ 3.2mm bore 10N25S
Stubby collet body
F
Stubby Collet body 0.020”-1/8”, Φ0.5mm- 3.2 mm bore 17CB20
Stubby standard ceramic cup
G
Standard ceramic cup 1/4”, Φ 6mm bore 13N08
Standard ceramic cup 5/16”, Φ 8mm bore 13N09
Standard ceramic cup 3/8”, Φ 10mm bore 13N10
Standard ceramic cup 7/16”, Φ 11mm bore 13N11
Standard ceramic cup 1/2”, Φ 13mm bore 13N12
Standard ceramic cup 5/8”, Φ 16mm bore 13N13
Gas lens body
H
gas lens body 0.020”, Φ 0.5mm bore 45V29
gas lens body 0.040”, Φ 1.0mm bore 45V24
gas lens body 1/16”, Φ 1.6mm bore 45V25
