200A - INVERTER MULTI-PROCESS WELDER
WT200MP
Powerful - 200A welding power up to 12mm steel thickness
Portable - Only 13kg super light weight and portable
Multi-Process - All in one machine for ARC, MIG and TIG
• Compact design - only 13kg
• MIG, TIG and ARC welding
• Latest IGBT inverter technology for the best results
• Inductance adjustment for precise weld control
• Optional spool gun available for aluminium and silicon bronze
• MIG 60% duty cycle @160A, ARC 60% duty cycle @ 130A
• 230V single phase on 15A plug
• Live digital displays for accurate feedback of welding output
• Stepless voltage and wire feed control for optimum weld control
• Lift TIG with optional TIG torch
• 3m Binzel Euro Connect MIG torch
• Exceptional results on gasless welding!
Cutting edge IGBT Inverter Technology with MIG, TIG and ARC processes available.
Produces professional results on workshop or on-site projects!
With 15A Plug - Ideal for workshop projects - cars, trailers and structural steel!
TAKES
15KG SPOOL
OF WIRE
OPTIONAL
SPOOL GUN
FOR
ALUMINIUM
(#13323)
60% @ 130A - MIG
60% @ 120A - ARC
Dimensions: (L x W x H) 485 x 220 x 390mm
Weight: 13kg
Input Power: 230V, 15A
Max. Input Current: 29.4A
Generator Capacity: 7kVA
Output Power:
Duty Cycle:
Electrode Size: 1.6 - 4.0mm
Wire Size: 0.6, 0.8, 0.9, 0.10
Spool Size: 5kg / 15kg
60% @ 160A - MIG
60% @ 130A - ARC
40 - 200A - MIG
30 - 170A - ARC
Welding Gloves
(#AWG02)
4 Sensor Auto Helmet
with grind
function
(#DW3000)
2 Sensor Auto Helmet
(#DW2500)
Flip Front Helmet
(#AFF1000)
Welding Magnet
(#WMG05)
Spool Gun for Alloy
(#13323)
Tips
0.6 (#MMT1506)
0.8 (#MMT1508)
0.9 (#MMT1509)
Chipping Hammer
(#SPCH)
TIG Torch
(#TWP17V-12-2D + CP3550)
Optional accessories to help you get the job done!
MIG Wire
0.6 (#MWM5KG06)
0.8 (#MW5KG08)
0.9 (#MW5KG09)
Flux Cored
0.8 (#MWMS08FC)
0.9 (#MWMS09FC)
0.9 (#MW5KG09FC)
MWMS = Mini Spool
MW5KG = 5kg
FC = Flux Cored
