Wellsys i16 - Model Designations and Specifications

i16 Manual Page 8 - Revision: 2-09-2023
MODEL/PART DESIGNATIONS
BRAND NAME
DESCRIPTION
MODEL -
PART NUMBER
i16 Countertop Unit
i16 – Hot, Ambient, Ice
i16
Z10534-(YYMMDD)-00XXX
SPECIFICATIONS
ITEM
I16
Water Connection
¼” Quick Connect
Rate Voltage
AC 120V/60Hz
Power Consumption
4.9A (565W)
Power Cord
1.9m (6.3ft)
IP Class
IPX1
Climate Class
N Class (32°C +/- 1°C) (89.6°F +/- 33.8°F)
Safety Device
Overheating protector. Water Level Detector. Water leakage shut-off valve. Fuse.
Hot Tank Size
1.25 Liters (42.3oz)
Ice Storage
16.5lbs (7.3kg) (Max)
Recommended Service
Pressure
14-100psi (1-7 kgf/cm²)
Environmental Temperature
Max: 100°F (37.7°C) Min: 50°F (10°C)
Source Water Temperature
Max: 90°F (32.2°C) Min: 40°F(4.5°C)
Relative Humidity
55% at 78°F(25.5°C)
Refrigerant Gas
R134a (2.6oz +/-0.03oz)
R134a Pressures
280psig (19.3bar) (High Side)
