ATA-171/172/171P/171M (ATA-S1/S2/P/M)
User’s Guide
40
ICMP Not Echo Default setting is No (do not activate). Once activated all ping messages
will not be responded.
Send Anonymous
CID
Default setting is No (do not activate). Once activated the device will not
send its own number.
Management from
WAN
Default setting is Yes (do not activate). Once activated the device will
restrict users to connect to it’s WAN port (Note: Only supported in
ATA171m).
Billing Signal (*) Default setting is Disabled (do not activate). Once activated the device
will send a signal to notify about the billing status (Polarity Reversal,
Tone_12K, Tone_16k) Support FXS Port
CPC Delay Default is 2 seconds, allows the system the ability to adjust the time taken
to lower the voltage to 0V upon disconnection. Support FXS Port
CPC Duration Default value is 0ms (do not lower any voltage). Specifies how long the
voltage will remain in ms when it is lowered to 0V.
Send Flash event Default setting is Disabled (do not activate). Provides two methods for
sending flash event messages; DTMF Event and SIP Info.
SIP Encrypt Default setting is Disabled (do not activate). SIP’s encryption method,
four options to choose from; INFINET, AVS, WALKERSUN1,
WALKERSUN2. Only works under environments that provide these
services.
PPPoE retry period
(*)
Default value is 5 seconds, range is from 5~255. Specifies the time
taken to redial when PPPoE dialing fails.
System Log Server
(*)
Specifies the location of the System log server where log information will
be stored.
System Log Type
(*)
Default setting is None (do not activate). Specifies the format of system
log messages, four to choose from; None, Call Statistics, Debug
Information and Both.
Submit [Button] Save setting value.
Reset [Button] Clean all setting.
