ATA-171/172/171P/171M (ATA-S1/S2/P/M)
User’s Guide
5
2 Keypad Interface for The ATA
You can use the PSTN phone keypad to operate the ATA. Please follow the instruction to configure
your terminal adapter.
Group IVR Action IVR Menu Choice Parameter(s) Notes:
Function
Dial out from
PSTN Line
0＊
None
Press 0* can pass call to PSTN
Line, user can dial out from PSTN
Line. (For 171P and 171M)
Function
Unlock keypad
setting
#190# None
After you unlock keypad setting,
then you may configure the ATA.
Function Reboot #195# None
After you hear “Option Successful,”
hang-up. The system will reboot
automatically.
Function Factory Reset #198# None
System will automatically reboot.
WARNING: ALL “User-Changeable”
NONDEFAULT SETTINGS WILL
BE LOST! This will include network
and service provider data.
Function
Enable PPTP
client
#116# None
System will automatically reboot
and PPTP client will be enabled
Function
Disable PPTP
client
#117# None
System will automatically reboot
and PPTP client wll be disabled
Function Enable VLAN #118# None
System will automatically reboot
and VLAN will be enabled.
Function Disable VLAN #119# None
System will automatically reboot
and VLAN will be disabled
Function
Enable Call
Waiting
#138# None
System will automatically reboot
and Call Waiting will be enabled.
Function
Disable Call
Waiting
#139# None
System will automatically reboot
and Call Waiting will be disabled.
Function
Enable
Anonymous
#140# None
System will automatically reboot
and Send Anonymous CID will be
enabled.
Function
Disable
Anonymous
#141# None
System will automatically reboot
and Send Anonymous CID will be
disabled.
Function Blind Transfer #510# None
Can only be performed in a phone
call conversation. For 171M, this
will transfer the current IP line to
another IP line.
Function
Attendant
Transfer
#511# None
Can only be performed in a phone
call conversation. For 171M, this
will transfer the line to IP from
PSTN (must be in IP mode to
execute this command)
Function
3-way calling (IP
Conference)
#512# None
Can only be performed in a phone
call conversation.
Function
Attendant
Transfer
#514# None
Can only be performed in a phone
call conversation. For 171M, this
will transfer the line to PSTN from
IP (must be in PSTN mode to
execute this command)
Info
Check WAN IP
Address
#126# None
IVR will announce the current WAN
IP address of the ATA
Info
Check LAN IP
Address
#120# None
IVR will announce the current LAN
IP address of the ATA
Info Check IP Type #121# None
IVR will announce if DHCP in
enabled or disabled.
Info
Check the Phone
Number
#122# None
IVR will announce current in use
VoIP number
Info
Check Network
Mask
#123# None
IVR will announce the current
network mask of the ATA.
Info
Check Gateway
IP Address
#124# None
IVR will announce the current
gateway IP address of the ATA.
Info
Check Primary
DNS Server
Setting
#125# None
IVR will announce the current
setting in the Primary DNS field.
Info
Check Firmware
Version
#128# None
IVR will announce the version of the
firmware running on the ATA.
Setting Set DHCP client #111# None The system will change to DHCP
