ATA-171/172/171P/171M (ATA-S1/S2/P/M)
User’s Guide
55
-24- weblogo function
Index Command Description
1 ? Show 'weblogo' Option
2 -on Vender Logo
3 -off Default Logo
4 (null) Show weblogo Setting
-25- dsp function is to show dsp code type.
-26- addport function is to add Nat Port Mapping
-27- cid function
Index Command Description
1 ? Show 'cid' Option
2 -off Disable Slic Cid signal
3 -1 Tx FSK after 1st Ring
4 -2 Tx FSK before 1st Ring
5 -3 Tx DTMF before 1st Ring
6 -4 Tx FSK with Line reversal before 1st Ring
7 -5 Tx DTMF with Line reversal before 1st Ring
8 -time FSK cid with time message
9 -single Single type FSK CID
10 (null) Show Cid Option
-28- slic function
Index Command Description
1 ? Show 'slic' Option
2 -ring Issue Ring signal
3 -r read slic addr
4 -w write slic addr
5 -a read all slic reg
6 (null) Show slic register
-29- ver function is to show Firmware Version.
