Wen 3625 User Manual

14
ADJUSTING THE BLADE BEVEL (FIG. 10)
Bevel your mini circular saw blade from 45° to 90° to cut your
workpiece on an angle. The saw’s maximum cutting depth at 90°
is 1-11/16 inch (43 mm), at 45° it is 1-1/8" (28 mm) . Be sure
to set your saw to the proper depth for the angle you are using
(see Page. 12).
1. Unplug your mini circular saw from the power source.
2. Flip up the bevel locking knob to loosen it.
3. Adjust the bevel locking knob to your desired angle between
45° to 90°. Your mini circular saw is pre-set to 90°, which is a
perpendicular, straight cut through your workpiece.
4. Press down on the bevel locking knob to securely tighten the
bevel setting.
Fig. 10
Bevel Scale
Bevel
Locking
Lever
ASSEMBLY & ADJUSTMENTS
