Wen 3625 User Manual

TABLE OF CONTENTS
Specifications .................................................................................. 2
Introduction .................................................................................... 3
General Safety Rules ....................................................................... 4
Specific Safety Rules for the Mini Circular Saw ............................... 6
Electrical Information ...................................................................... 9
Know Your Mini Circular Saw ........................................................ 10
Assembly & Adjustments .............................................................. 11
Operation ...................................................................................... 15
Maintenance .................................................................................. 16
Troubleshooting Guide .................................................................. 17
Exploded View & Parts List ........................................................... 18
Warranty Statement ....................................................................... 21
SPECIFICATIONS
Model Number 3625
Motor 120V AC, 60 Hz, 5A
Motor Speed (No-Load) 3500 RPM
Blade Diameter 4-1/2" (115 mm)
Arbor Size 3/8" (10mm)
Maximum Cutting Depth
90° 1-11/16" (43 mm)
45° 1-1/8" (28 mm)
Blade Body Thickness 1.2 mm
Blade Teeth Thickness 1.8 mm
Laser Battery Type LR44
Laser Power 0.278 mW
Laser Class II, 650 nm
Dust Tube Outer Diameter 1.35 to 1.5 in.
Base Plate Dimensions 9.5 in. x 3.4 in. x .079 in.
Assembled Dimensions 16.2 in. x 4.3 in. x 4.3 in.
Product Net Weight 5.8 lbs
Replacement wood-cutting blades (Model BL11510W) can be ordered at wenproducts.com.
2

Wen 3625 Specifications

General

Brand	Wen
Model	3625
Category	Saw
Language	English
