Wen 3705 User Manual

28
Exploded view and parts list (continued)
Part#
Stock#
Description
Qty
Part#
Stock#
Description
Qty
92
3705-092
Front cover
1
119
3705-119
Splitter bracket
1
93
3705-093
Bolt M5×20
3
120
3705-120
Bolt M6×12
4
94
3705-094
Arbor sh af t
1
121
3705-121
Wi n g nut M6
1
96
3705-096
Blade
1
122
3705-122
Twist spring
1
97
3705-097
Ou te r flange
1
123
3705-123
Axis cover2
2
98
3705-098
Arbor nut
1
124
3705-124
Block plate
1
99
3705-099
Dial pointer
1
125
3705-125
Quakeproof mat
1
100
3705-100
Miter gauge
1
126
3705-126
Bolt M6×40
1
101
3705-101
Miter gauge lock knob
1
127
3705-127
Anti-kickback pawl
2
102
3705-102
Mat plate
1
128
3705-128
Axis cover3
2
103
3705-103
Column pin
1
129
3705-129
Column pin
1
104
3705-104
Angle ruler button
1
130
3705-130
Spring column pin
1
105
3705-105
Axis flange
6
131
3705-131
Splitter
1
106
3705-106
Ruler
1
143
3705-143
Bolt M6X12
2
108
3705-108
Bolt M6×20
6
144
3705-144
Lock m a t
2
109
3705-109
Table
1
145
3705-145
Wrench
1
110
3705-110
Bolt M6×25
1
146
3705-146
Rip fence
1
111
3705-111
Bolt M6×35
1
147
3705-147
Pin wrench
1
112
3705-112
Table insert
1
148
3705-148
Mat washer
2
113
3705-113
Blade guard
1
149
3705-149
Bolt M5X10
2
114
3705-114
Bolt M6×12
2
150
3705-150
Nut M6
1
115
3705-115
Nut M6
2
151
3705-151
Bolt M4×10
1
116
3705-116
Pivot bolt M6×50
1
152
3705-152
Bolt M4×10
3
117
3705-117
Pivot plate
1
153
3705-153
Bolt M5X10
8
118
3705-118
Bolt M6X16
1
