15
EXPLODED VIEW & PARTS LIST
NO. PART DESCRIPTION QTY
1 3960-001 Blade Tension Knob 1
2 3960-002 Flat Washer 1
3 3960-003 Blade Tension Spring 1
4 3960-004 Carriage Bolt 1
5 3960-005 Pulling Plate 1
6 3960-006 Socket Head Screw 1
7 3960-007 Shaft 1
8 3960-008 Lock Catch 2
9 3960-009 Hex Nut 1
10 3960-010 Lock Washer 1
11 3960-011 Bevel Support Plate 1
12 3960-012 Upper Wheel Shaft 1
13 3960-013 Ball Bearing (6000ZZ) 4
14 3960-014 Upper Wheel 1
15 3960-015 Int. Retaining Ring 4
16 3960-016 Ext. Retaining Ring 2
17 3960-017 Tire 2
18 3960-018 Upper Wheel Cover 1
19 3960-019 Blade 1
20 3960-020 Lower Wheel Cover 1
21 3960-021 Lock Nut 2
22 3960-022 Bushing 2
23 3960-023 Socket Head Screw 2
24 3960-024 Lower Wheel 1
25 3960-025 Thread Forming Screw 3
26 3960-026 Drive Pulley 1
27 3960-027 Lower Wheel Shaft 1
28 3960-028 Hex Nut 4
29 3960-029 Hex Bolt 4
30 3960-030 Lock Nut 1
31 3960-031 Lifting Handle 1
32 3960-032 Pan Head Screw 2
33 3960-033 Frame 1
34 3960-034 Switch Box 1
35 3960-035 Pan Head Screw 2
36 3960-036 Switch Mounting Plate 1
37 3960-037 Thread Forming Screw 1
38 3960-038 Switch 1
39 3960-039 Lock Washer 2
40 3960-040 Serrated Washer 2
41 3960-041 Pan Head Screw 2
42 3960-042 Hex Nut 1
43 3960-043 Flat Washer 2
44 3960-044 Bushing 1
45 3960-045 Brush 1
NO. PART DESCRIPTION QTY
46 3960-046 Carriage Blot 1
47 3960-047 Foot 4
48 3960-048 Belt 1
49 3960-049 Dust Port 1
50 3960-050 Pan Head Screw 3
51 3960-051 Lock Nut 2
52 3960-052 Catching Knob 2
53 3960-053 Socket Head Screw 2
54 3960-054 Socket Head Screw 2
55 3960-055 Ball Bearing (606ZZ) 2
56 3960-056 Flat Washer 2
57 3960-057 Support Rod 1
58 3960-058 Socket Head Screw 4
59 3960-059 Ball Bearing (605ZZ) 4
60 3960-060 Flat Washer 4
61 3960-061 Lower Guide Block 1
62 3960-062 Square Nut 4
63 3960-063 Support Block 1
64 3960-064 Socket Head Screw 2
65 3960-065 Flat Washer 2
66 3960-066 Socket Head Screw 2
67 3960-067 Lower Protecting Cover 1
68 3960-068 Flat Washer 2
69 3960-069 Pan Head Screw 2
70 3960-070 Strain Relief 2
71 3960-071 Guide Plate 1
72 3960-072 Set Screw 1
73 3960-073 Pinion 1
74 3960-074 Adjustment Knob Seat 1
75 3960-075 Flat Washer 1
76 3960-076 Socket Head Screw 2
77 3960-077 Adjustment Knob 1
78 3960-078 Upper Guide Block 1
79 3960-079 Support Rod 1
80 3960-080 Flat Washer 2
81 3960-081 Socket Head Screw 1
82 3960-082 Socket Head Screw 1
83 3960-083 Flat Washer 2
84 3960-084 Socket Head Screw 2
85 3960-085 Upper Cover Assembly 1
86 3960-086 Square Nut 1
87 3960-087 Guide Block 1
88 3960-088 Flat Washer 2
89 3960-089 Socket Head Screw 2
90 3960-090 Flat Washer 8mm 1
To Next Page
