SPECIFICATIONS
DC output
Rated Voltage 12 V DC
Rated Amperage 8.3 A
Rated Wattage 100 W
AC output
Rated Wattage 11000 Watts
Surge Wattage 13000 Watts
Rated Voltage 120 V/ 240 V
Rated Amperage 91.6 A/ 45.8 A
Frequency 60 Hz
Phase Single
Dimensions
Length: 32.50 inches
Width: 23.625 inches
Height: 27 inches
Weight 330 lbs
Engine
Engine type 4 stroke, OHV, twin cylinder with forced air cooling system
Spark plug gap 0.7 - 0.8 mm (0.028 - 0.031 in)
Spark plug torque 1/2 - 3/4 turn after gasket contacts base or 15 ft.lb
Displacement 670 cc
Fuel tank capacity 8 gallons 87 octane minimum
Oil capacity 50.7 fl.oz
Lubrication system Oil Pump
Run time on 50% load 7.5 hours
Noise rating 82 dB at 22 feet
Spark plug Torch F5RTC
