SPECIFICATIONS
Rated Wattage 1800 Watts
Surge Wattage 2250 Watts
Rated Voltage AC: 120V, DC: 5V
Rated Amperage AC: 15A, DC: 1A (Top), 2.1A (Bottom)
Phase Single
Frequency 60Hz
Product Dimensions
Length: 19 in.
Width: 11.5 in.
Height: 18.2 in.
Product Net Weight 48.5 lbs
Engine Type 4-stroke, OHV, single cylinder with forced air cooling system
Engine Displacement 79.7 cc
Fuel Tank Capacity 1 US gallon (3.8 L), 87 octane minimum
Oil Capacity 11.8 fl. oz. (0.35 L)
Half-Load Run Time 6 hours
Lubrication System Splash Lubrication
Noise rating:
(tested from 22 ft away
with an ambient dB rat-
ing of 44 dB)
52 dBA at no load
53 dBA at 1/4 load
54 dBA at 1/2 load
57 dBA at 3/4 load
Spark Plug Type NGK CR5HS/Torch A5RTC
Spark Plug Gap 0.7 - 0.8 mm (0.028 - 0.031 in)
Spark Plug Torque 1/2 - 3/4 turn after gasket contacts base or 15 ft-lbs
GENERATOR
ENGINE
30
