Wen 56360iX User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
24 56360iX-024 Insulator 1
25 56360iX-025 Gasket, Carburetor 1
26 56360iX-026 Carburetor 1
27 56202i-127 Stepping Motor 1
28 56202i-128 Screw, M4x6 2
29 56360iX-029 Clamp 1
30 56360iX-030 Fuel Hose 1
31 56360iX-031 Intake Manifold 1
32 56202i-132 Clamp 1
33 56360iX-033 Gasket, Cylinder Head 1
34 56202i-134
Pin, φ8x12
2
35 56360iX-035 Push Rod 2
36 56360iX-036 Exhaust Valve 1
37 56360iX-037 Intake Vavle 1
38 56360iX-038 Tappet 2
39 56360iX-039 Piston Ring Set 1
40 56360iX-040 Circlip 2
41 56360iX-041 Piston Pin 1
42 56360iX-042 Piston 1
43 56360iX-043
Connecting Rod
Assembly
1
44 56360iX-044 Crankcase 1
45 56360iX-045 Oil Sensor 1
46 56202i-146 Bolt, M6×16 2
47 56202i-147 Bolt, M6x12 9
48 56360iX-048 Crankshaft 1
49 56360iX-049 Camshaft 1
50 56360iX-050 Gasket, Cylinder Cover 1
51 56360iX-051 Crankcase Cover 1
52 56360iX-052 Bolt, M6x25 8
53 56202i-153 Dipstick 1
54 56360iX-054 Trigger 1
55 56360iX-055
Oil Seal, φ25xφ41.25x6
1
56 56360iX-056 Stator Assembly 1
57 56360iX-057 Bolt, M6x38 3
58 56360iX-058 Cooling Fan 1
59 56360iX-059 Starter Cup 1
60 56360iX-060 Nut, M14x1.5 1
ENGINE
35
NO. PART NO. DESCRIPTION QTY.
61 56360iX-061 Recoil Starter 1
62 56360iX-062 Blower Housing 1
63 56360iX-063 Air Filter Element 1
64 56360iX-064 Air Filter Cover 1
65 56360iX-065 Rotor 1
66 56360iX-066 Recoil Starter 1
67 56360iX-067 Oil Thrower Gear 1
68 56202i-167 Bolt, M6x14 2
69 56360iX-069 Ignition Coil 1
70 56360iX-070 Bearing, 6205E 1
71 56360iX-071
Self-tappling Screw,
ST4.8x20
2
72 56360iX-072 Gasket, Cylinder Cover 1
73 56360iX-073 Cylinder Head Baffle 1
74 56360iX-074 Cylinder Head Baffle 1
75 56360iX-075 Clip Base 1
76 56360iX-076 Clip Base 1
77 56360iX-077
Self-tappling Screw,
ST4.2x16
6
78 56360iX-078 Idle Spring 1
79 56360iX-079 Fuel Hose Jacket 1
80 56360iX-080 Fuel Hose Body 1
81 56360iX-081 Fuel Hose Jacket 1
82 56360iX-082 Clip 1
83 56360iX-083 Bolt, M6x45 3
84 56360iX-084 Clip 2
85 56360iX-085
Pin, φ10x16
2
86 56360iX-086 Bolt, M6x45 1
87 56360iX-087
Self-tappling Screw,
ST4.2x25
5
88 56360iX-088 Wind Board 1
89 56360iX-089 Wind Board 1
90 56360iX-090
Washer, φ14.2x0.5xφ21
2
91 56360iX-091 Corrugated Gasket 1
92 56360iX-092
Valve Adjust Cap,
Exhaust
2
93 56360iX-093 Bolt, M6x12 2
