SPECIFICATIONS
GENERATOR
ENGINE
3
Surge Wattage 4500 Watts
Rated Wattage 3500 Watts
Rated Voltage
AC: 120V
DC: 12V (Cigarette Lighter), 5V (USB)
Rated Amperage 29.16A
Phase Single
Frequency 60 Hz
Decibel Rating 58 dB
Product Dimensions
Length: 23.2 in. (590 mm)
Width: 18 in. (456 mm)
Height: 20.1 in. (511 mm)
Product Net Weight 99.2 lbs (45 kg)
Engine Type
4-Stroke, OHV, Single Cylinder with Forced Air Cooling
System
Engine Displacement 212cc
Engine Speed 3600 RPM
Fuel Tank Capacity 2.2 US Gallons (8.50 L), 87 Octane Minimum
Oil Capacity 18.6 fl. oz. (0.55 L)
Half-Load Run Time 8.5 Hours
Lubrication System Splash Lubrication
Spark Plug Type NGK BPR6ES / Torch F6RTC
Spark Plug Gap 0.7 - 0.8 mm (0.028 - 0.031 in.)
Spark Plug Torque 1/2 - 3/4 turn after gasket contacts base or 15 ft-lbs
