Wen 6524 User Manual

17
EXPLODED VIEW AND PARTS LIST
No. Part No. Description
70 6523-070 Carbon Brush
71 6523-071 Carbon Brush Spring
72 6523-072 Cord Clamp
73 6523-073 Washer, M4
75 6523-075 Tap Screw, M4
76 6523-076 Flat Washer, M6
77 6523-077 Bearing Cover
78 6523-078 Tap Screw, M4
79 6523-079 Bearing Sleeve, Upper
80 6523-080 Compression Spring
81 6523-081 Spindle
83 6523-083 Woodruff Key, 5 x 19
84 6523-084 Flat Washer, M17
85 6523-085 Washer, M17
86 6523-086 Pulley Plate
87 6523-087 Pulley, Lower
88 6523-088 Belt, 3/8” x 160XL
89 6523-089 Belt , 1/4” x 160XL
90 6523-090 Pulley, Upper
91 6523-091 Bearing Sleeve, Lower
92 6523-092 Metal Switch Plate
93 6523-093 Plastic Switch Plate Cover
94 6524-094 Switch Pivot Plate Base
95 6523-095 Switch Pivot Plate
96 6523-096 Switch
97 6523-097 Switch Key
99 6523-099 Phillips Screw, M4
100 6523-100 Spindle Nut Wrench
102 6523-102 Throat Plate, 1”
103 6523-103 Knob
104 6524-104 Hex Nut Knob, M8
No. Part No. Description
105 90225-111 Sanding Drum, 2"
106 90225-110 Sanding Drum, 1-1/2"
107 6523-107 Cap Screw
108 6523-108 Throat Plate, 3/4”
109 90225-109 Sanding Drum, 1"
110 90225-108 Sanding Drum, 3/4"
111 6523-111 Throat Plate, 1/2”
113 6523-113 Spindle Washer, 7/8"
114 6523-114 Rubber Foot
116 6523-116 Spindle Washer, 5/8"
117 6523-117 Spindle Washer, 1-3/4"
118 6523-118 Sanding Sleeve, 2” 80-Grit
119 6523-119 Sanding Sleeve, 1-1/2” 80-Grit
120 6523-120 Sanding Sleeve, 1” 80-Grit
121 6523-121 Sanding Sleeve, 3/4” 80-Grit
122 6523-122 Sanding Sleeve, 1/2” 80-Grit
124 6523-124 Bevel Plate Bracket
125 6523-125 Base
126 6523-126 Phillips Screw, M5
127 6523-127 Table Insert
128 6523-128 Strain Relief
130 6523-130 Power Cord
131 6523-131 Cord Clamp
132 6523-132 Throat Plate, 1-1/2”
133 6523-133 Throat Plate, 2”
134 6523-134 Bottom Guard
135 6524-135 Motor Vent Cover
136A 6523-136A Brush Assembly
136 6524-136 Circuit Breaker
137 6524-137 Circuit Breaker Nut
138 6524-138 Wire Lead
