AMPERAGE
REQUIRED GAUGE FOR EXTENSION CORDS
25 ft. 50 ft. 100 ft. 150 ft.
3.5 A 18 gauge 16 gauge 16 gauge 14 gauge
KNOW YOUR BELT & SPINDLE SANDER
A - Work Table
B - Sanding Belt
C - Belt Tracking Adjustment Knob
D - Belt Tensioning Lever
E - Work Stop
F - Spindle
G - Spindle Nut
H - Sanding Drum w/ Sleeve
I - Table Insert
J - Dust Port
K - Throat Plate Storage
L - Table Tilt Locking Knob
M - ON/OFF Switch
N - Sanding Drum Storage
O - Spindle Knob
P - Circuit Breaker
UNPACKING
A - Belt Sanding Attachment
B - 80-Grit Sanding Belt (4 x 24 in.)
C - Spindle Nut Wrench (13 mm/10 mm)
D - Sanding Drums (3/4, 1, 1-1/2, & 2 in.) (4 pcs)
NOTE: There is no 1/2 in. drum; the 1/2 in.
sleeve fits directly on the spindle.
E - 80-Grit 4-1/2 in. Sanding Sleeves (1/2, 3/4, 1,
1-1/2, & 2 in. diameter) (5 pcs)
F - Table Insert
G - Throat Plates (1/2, 3/4, 1, 1-1/2, & 2 in.)
H - Spindle Washers (5/8, 7/8, & 1-3/4 in. outer
diameter) (3 pcs)
I - Hex Nut (M8 - 1.25)
J - Spindle Knob
O
J
P
To Next Page
