EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 AT6535-001 Hex Nut M10 1
2 AT6535-002 (2") Upper Washer 1
3 AT6535-003 (2") Rubber Drum 1
4 AT6535-004 Lower Washer 1
5 AT6535-005 Connecting Shaft 1
6 AT6535-006
(2") Throat Plate,
Bevel
1
7 AT6535-007 Iron Work Table 1
8 AT6535-008 Hex Nut M6 2
9 AT6535-009 Hex Screw M6x18 2
10 AT6535-010 Dust Guard 1
11 AT6535-011 Dust Box 1
12 AT6535-012 Screw M5x8 4
13 AT6535-013 Right Bevel Plate 1
14 AT6535-014 Flat Washer Ø5 8
15 AT6535-015 Spring Washer Ø5 8
16 AT6535-016 Screw M5x16 4
17 AT6535-017 Left Bevel Plate 1
18 AT6535-018 Cover 1
19 AT6535-019 Screw M4x10 6
20 AT6535-020 Screw M6x16 18
21 AT6535-021 Spring Washer Ø6 18
22 AT6535-022 Flat Washer Ø6 20
23 AT6535-023 Stepped Screw 2
24 AT6535-024 Table Bevel Knob 2
25 AT6535-025 Left Locating Plate 1
26 AT6535-026 Screw M5x12 4
27 AT6535-027 Dust Box Holder 1
28 AT6535-028 Right Locating Plate 1
29 AT6535-029 Angle Pointer 1
30 AT6535-030 Screw M4x6 1
31 AT6535-031 Motor Fixed Plate 1
32 AT6535-032 Rubber Washer 1
No. Part No. Description Qty.
33 AT6535-033 Screw ST4.2x13 12
34 AT6535-034 Bearing Cover 2
35 AT6535-035 Bearing 6203 2
36 AT6535-036 Felted Wool Washer 2
37 AT6535-037 Rubber Washer 2
38 AT6535-038 Pulley Support 1
39 AT6535-039 Pulley 1
40 AT6535-040 Tension Pulley 1
41 AT6535-041 Elastic Washer Ø6 2
42 AT6535-042 Locating Plate 1
43 AT6535-043 Elastic Washer Ø17 2
44 AT6535-044 Washer 2
45 AT6535-045 Woodruff Key 5x19 1
46 AT6535-046 Shaft 1
47 AT6535-047 Screw ST4.2x16 16
48 AT6535-048 Pulley Plate 2
49 AT6535-049 Driving Pulley 1
50 AT6535-050 Belt 1 1
51 AT6535-051 Belt 2 1
52 AT6535-052 Passive Pulley 1
53 AT6535-053 Rubber Washer 1
54 AT6535-054 Screw ST4.2x23 8
55 AT6535-055 Bearing Cover 1
56 AT6535-056 Bearing Sleeve Large 1
57 AT6535-057 Compression Spring 1
58 AT6535-058 Bearing 6001 1
59 AT6535-059 Elastic Washer Ø12 1
60 AT6535-060 Rotor 1
61 AT6535-061 Bearing 608 1
62 AT6535-062 Connecting Plate 1
63 AT6535-063 Stator 1
64 AT6535-064 Magnetic Shoe 1 1
65 AT6535-065 Magnetic Shoe 2 1
18
