Wen AT6535

No. Part No. Description Qty.
66 AT6535-066 Rear Cover 1
67 AT6535-067 Carbon Brush 2
68 AT6535-068 Carbon Brush Spring 2
69 AT6535-069 Brush Holder 2
70 AT6535-070 Tension Disc 2
71 AT6535-071 Washer Ø4 4
72 AT6535-072 Flat Washer Ø4 6
73 AT6535-073 Screw ST4.2x110 2
74 AT6535-074 Rubber Key 1
75 AT6535-075 Rectifier Bridge 1
76 AT6535-076 Screw ST4.2x19 5
77 AT6535-077 Connecting Wire 1 1
78 AT6535-078 Connecting Wire 2 1
79 AT6535-079 Cable Clamp 2
80 AT6535-080 Power Cord & Plug 1
81 AT6535-081
(1/2") Throat Plate,
Bevel
1
82 AT6535-082
(1/2") Horizontal
Throat Plate
1
83 AT6535-083 Switch Locating Plate 1
84 AT6535-084 Power Cord Holder 1
85 AT6535-085 Warning Label 1
86 AT6535-086
(2") Throat Plate,
Horizontal
1
87 AT6535-087
(1-1/2") Throat Plate,
Horizontal
1
88 AT6535-088
(1-1/2") Throat Plate,
Bevel
1
89 AT6535-089
(1") Throat Plate,
Horizontal
1
90 AT6535-090
(1") Throat Plate,
Bevel
1
No. Part No. Description Qty.
91 AT6535-091
(3/4") Throat Plate,
Horizontal
1
92 AT6535-092
(3/4") Throat Plate,
Bevel
1
93 AT6535-093 Warning Label 1
94 AT6535-094 Plastic Base 1
95 AT6535-095 (1/2") Upper Washer 1
96 AT6535-096 (3/4") Upper Washer 1
97 AT6535-097 (1") Upper Washer 1
98 AT6535-098 (1-1/2") Upper Washer 1
99 AT6535-099 Spindle Nut Wrench 1
100 AT6535-100 Switch Retainer Plate 1
101 AT6535-101
Switch Locating Piece
(Lower)
1
102 AT6535-102 ON/OFF Switch 1
103 AT6535-103
Switch Locating Piece
(Upper)
1
104 AT6535-104 Auxiliary Locating Ring 1
105 AT6535-105 Spring Washer Ø4 4
106 AT6535-106 Screw M4x19 4
107 AT6535-107 Rubber Foot 4
108 AT6535-108 Brand Label 1
109 AT6535-109 Specifications Label 1
110 AT6535-110 Connecting Wire 1
111 AT6535-111 Clamp 3
112 AT6535-112 Screw ST4.2x10 14
113 AT6535-113 Connecting Wire 1
114 AT6535-114 (3/4") Rubber Drum 1
115 AT6535-115 (1") Rubber Drum 1
116 AT6535-116 (1-1/2") Rubber Drum 1
118 AT6535-118 Plastic Base Plate 1
EXPLODED VIEW & PARTS LIST
19
NOTE: Replacement parts can be purchased from wenproducts.com, or by calling our customer service at
(800) 232-1195, M-F 8-5 CST. Parts and accessories that wear down over the course of normal use (e.g.
sanding sleeves, sanding drums, carbon brushes, etc.) are not covered by the two-year warranty.
