Wen BA4664 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
75 3970-075 Lock Washer, 8mm 4
76 3970-076 Flat Washer, 8mm 4
77 3970-077 Hex Head Bolt, M8x20 4
78 3970-078 Hex Head Bolt, M12x35 1
79 3970-079 Belt Cover 1
80 3970-080 Knob 1
81 3970-081 Flat Washer, 4mm 1
82 3970-082 Pan Head Screw, M4x8 1
83 3970-083 Set Screw, M8x8 1
84 3970-084 Motor Pulley 1
85 3970-018 Key, 5x5x28mm 1
86 3970-086 Motor 1
87 3970-087 Front Guide Base 1
88 3970-088 Flat Washer, 8mm 1
89 3970-089 Lock Washer, 8mm 1
90 3970-090 Hex Head Bolt, M8x30 1
91 3970-091 Nut, M8 2
92 3970-092 Lock Washer, 8mm 2
93 3970-093 Ball Bearing, 629ZZ 1
94 3970-094 Shaft 1
95 3970-095 Front Blade Guide 1
96 3970-096 Bearing Mount 2
97 3970-093 Ball Bearing, 629ZZ 2
98 3970-098 Retaining Ring, 9mm 2
99 3970-099 Front Blade Guard 1
100 3970-100 Flat Head Screw, M6x16 2
101 3970-101 Nut, M8 2
102 3970-102 Lock Washer, M8 2
103 3970-103 Hex Head Bolt, M8x30 1
104 3970-104 Lock Washer, 8mm 1
105 3970-105 Flat Washer, 8mm 1
106 3970-093 Ball Bearing, 629ZZ 1
107 3970-094 Shaft 1
108 3970-108 Rear Blade Guide 1
109 3970-096 Bearing Mount 2
110 3970-093 Ball Bearing, 629ZZ 2
111 3970-098 Retaining Ring, 9mm 2
No. Part No. Description Qty.
112 3970-112 Rear Blade Guard 1
113 3970-113 Flat Washer, 4mm 2
114 3970-114 Pan Head Screw, M4x6 2
115 3970-115 Rear Guide Base 1
116 3970-116 Pan Head Screw, M6x10 1
117 3970-117 Flat Washer, 6mm 1
118 3970-118 Frame Guard 1
119 3970-119 Extension Guard 1
120 3970-120 Knob 1
121 3970-121 Pin With Chain 1
122 3970-122 Socket Head Screw, M10x35 2
123 3970-123 Lock Washer, 10m 2
124 3970-124 Flat Washer, 10mm 2
125 3970-125 Set Screw, M8x8 1
126 3970-126 Pivot Block 1
127 3970-127 Spring 1
128 3970-128 Spring Adjusting Screw 1
129 3970-129 Hex Head Bolt, M6x12 2
130 3970-130 Lock Washer, 6mm 2
131 3970-131 Flat Washer, 6mm 2
132 3970-132 Screw Support Plate 1
133 3970-133 Adjusting Rod 1
134 3970-134 Knob 1
135 3970-135 Adjusting Rod Support 1
136 3970-136 Hex Head Bolt, M8x20 8
137 3970-137 Flat Washer, 8mm 8
138 3970-138 Lock Washer, 8mm 8
139 3970-139 Nut, M8 8
140 3970-140 Pivoting Rod 1
141 3970-141 Spring Pin, 4x25mm 1
142 3970-142 Flat Washer, 6mm 1
143 3970-143 Hex Head Bolt 1
144 3970-144 Flat Washer, 8mm 1
145 3970-145 Hex Head Bolt, M8x40 1
143 3970-143 Hex Head Bolt 1
144 3970-144 Flat Washer 1
145 3970-145 Hex Head Bolt 1
23
