Wen BA4664 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
146 3970-144 Flat Washer, 8mm 1
147 3970-147 Vise Jaw 1
148 3970-148 Hex Head Bolt, M10x25 1
149 3970-149 Flat Washer, 10mm 1
150 3970-150 Movable 1
151 3970-151 Base 1
152 3970-152 Pan Head Screw, M5x8 2
153 3970-153 Flat Washer, 5mm 2
154 3970-154 Strain Relief 1
155 3970-155 Strain Relief Mounting Plate 1
156 3970-156 Hex Head Bolt, M12x70 1
157 3970-157 Nut, M12 1
158 3970-158 Set Screw, M8x12 1
159 3970-159 Safety Bracket 1
160 3970-160 Flat Washer, 8mm 1
161 3970-161 Hex Head Bolt, M8x16 1
162 3970-162 Nut, M5 2
163 3970-163 Cord Clamp 2
164 3970-164 Pin With Chain 1
165 3970-165 Flat Washer, 5mm 2
166 3970-166 Pan Head Screw, M5x16 2
167 3970-167 Set Screw, M8x8 1
168 3970-168 Work Stop 1
169 3970-169 Work Stop Rod 1
170 3970-170 Nut, M8 1
171 3970-171 Flat Washer, 8mm 1
172 3970-172 Switch Box 1
173 3970-173 Switch Mounting Plate 1
174 3970-174 Thread Forming Screw 2
175 3970-175 Strain Relief 2
176 3970-176 Power Cord 1
177 3970-177 Toothed Washer, 5mm 2
178 3970-178 Pan Head Screw, M5 2
179 3970-179 Switch 1
180 3970-180 Angle Scale 1
181 3970-181 Rivet 2
182 3970-182 Screw Support Block 1
No. Part No. Description Qty.
183 3970-183 Flat Washer, 6mm 2
184 3970-184 Lock Washer, 6mm 2
185 3970-185 Hex Head Bolt, M6x18 2
186 3970-186 Vise Nut 1
187 3970-187 Lead Screw 1
188 3970-188 Bushing 1
189 3970-189 Set Screw, M6x6 1
190 3970-190 Hex Head Bolt, M6x12 1
191 3970-191 Crank Handle 1
192 3970-192 Cotter Pin 2
193 3970-193 Transport Handle 1
194 3970-194 Leg A 2
195 3970-195 Leg B 2
196 3970-196 Nut, M8 8
197 3970-197 Lock Washer, 8mm 8
198 3970-198 Flat Washer, 8mm 8
199 3970-199 Carriage Bolt, M8x16 8
200 3970-200 Long Brace 2
201 3970-201 Short Brace 2
202 3970-202 Hex Nut, M6 2
203 3970-203 Flat Washer, 6mm 2
204 3970-204 Wheel 2
205 3970-205 Hex Head Bolt, M6x12 2
206 3970-206 Flat Washer, 6mm 2
207 3970-207 Lock Washer, 6mm 2
208 3970-208 Wheel Bracket 1
209 3970-209 Axle 1
210 3970-210 Cotter Pin 2
211 3970-211 Table 1
212 3970-212 Flat Head Screw, M6x16 1
213 3970-213 Table Support 1
214 3970-214 Flat Washer, 6mm 1
215 3970-215 Nut, M6 1
24
NOTE: Not all parts may be available for purchase.
Parts and accessories that wear down over the course
of normal use are not covered under the warranty.
