Wen CT1274

12
TOOL PURPOSE
Track Saws allow you to easily make miter cuts and rough cuts on large sheets of material. Refer to the following
diagrams to become familiarized with all the parts and controls of your track saw. The components will be referred
to later in the manual for assembly and operation instructions.
KNOW YOUR TRACK SAW
16. Dust Port
17. Spindle Lock
18. Mode Selector
19. Saw Blade
20. Slot for Parallel Guide
21. Carbon Brush Cover
22. Track Slot
16
17
18
20
21
22
19
